XDS
SKU: 9990217391
X-LAB RT9 Road Bike The X-LAB RT9 is built around one goal: delivering exceptional lightweight performance for riders who want to climb faster. Constructed from Toray T1100 carbon and refined through extensive structural analysis,...
AED 33,499.00
AED 33,499.00
Colour: Shadowbox
Size: S
X-LAB RT9 | Shadowbox

X-LAB RT9 | Shadowbox

AED 33,499.00
X-LAB RT9 | Shadowbox
X-LAB RT9 | Shadowbox
X-LAB RT9 | Shadowbox
X-LAB RT9 | Shadowbox
X-LAB RT9 | Shadowbox
X-LAB RT9 | Shadowbox
X-LAB RT9 | Shadowbox

X-LAB RT9 | Shadowbox

AED 33,499.00
Colour: Shadowbox
Size: S
GENERAL INFO
GENERAL INFO
x

X-LAB RT9 Road Bike

The X-LAB RT9 is built around one goal: delivering exceptional lightweight performance for riders who want to climb faster.

Constructed from Toray T1100 carbon and refined through extensive structural analysis, the RT9 frame weighs just 550 grams, while maintaining the stiffness and durability needed for high-level racing.

Its lightweight construction translates into quick acceleration, efficient power transfer, and less weight to carry uphill, making it a bike designed to come alive when the road starts climbing.

Built for riders chasing elevation, speed, and pure road performance, the RT9 represents X-LAB’s approach to creating an exceptionally light race machine.

Lightweight by design. Built to climb.

Key Features

Branta C50 ULR carbon wheelset with carbon spokes | 1,230 g

Branta carbon crankset with integrated power meter + Apple Find My anti-theft technology

Shimano Dura-Ace groupset

XDS carbon frameset with Toray T1100, Full bike 6.2kg



TECHNICAL SPECS
TECHNICAL SPECS
x
Frame XDS Carbon Frame, Toray T-1100 + M40X, UDH Compatible
Fork XDS Carbon Fork, Toray T-1100, 100x12mm Thru-axle
Handlebar / Stem Branta Carbon Integrated
Seatpost XDS Carbon Seatpost, 27.2mm
Rear Derailleur Shimano Dura-Ace RD-R9250 Di2
Front Derailleur Shimano Dura-Ace FD-R9250 Di2
Shifters Shimano Dura-Ace ST-R9270 Di2
Brakes Shimano Dura-Ace BR-R9270
Cassette Shimano Dura-Ace CS-R9200, 11-34T
Crankset Branta Carbon Power Meter Crankset, 52-36T,
29mm Alloy Spindle, Apple Find My Anti-Theft Technology
Bottom Bracket BSA 29mm
Rotors Shimano SM-MT900, Front: 160mm / Rear: 140mm
Chain Shimano CN-M9100
Wheelset Branta C50 ULR, Carbon Rims & Spokes, Ceramic Bearings
Tires Michelin Pro 5 700x28C
Max Tire Clearance: 30C
Saddle Selle Italia SLR Boost, Carbon Rails
Weight 6.20 kg / 13.64 lbs (Size L)
Size Options XS / S / M / L
GEOMETRY
GEOMETRY
x

Basic Geometry XS S M L
A — Seat Tube Length 430mm 460mm 480mm 500mm
B — Top Tube Length 498mm 520mm 540mm 563mm
C — Head Tube Length 110mm 120mm 137mm 157mm
D — Seat Tube Angle 75° 74.2° 74° 73.5°
E — Head Tube Angle 70.5° 71.7° 73° 73.5°
F — Chainstay 410mm 410mm 410mm 410mm
G — Wheelbase 972.5mm 977mm 978mm 992mm
H — Bottom Bracket Drop 74mm 74mm 72mm 72mm
I — Stack 510mm 525mm 543mm 567mm
J — Reach 362mm 372mm 384mm 396mm
K — Front Center 574mm 578mm 578mm 592mm
O — Stand Over 704mm 728mm 750mm 769mm


Component Geometry XS S M L
Fork Rake / Offset 50mm 50mm 44mm 44mm
Trail 68mm 61mm 59mm 56mm
Handlebar 360mm 360mm 380mm 400mm
Stem 80mm 100mm 100mm 120mm
Crankset 160mm 160mm 165mm 165mm
Seat Post 300mm 300mm 350mm 350mm
