XDS
SKU: 9990214441
The X-LAB AD8 105 Di2 is built for riders who want the performance of a race bike without compromising everyday rideability. Inspired by the WorldTour-proven AD9, it combines aerodynamic efficiency, responsive handling, and lightweight...
AED 21,229.00
AED 21,229.00
Colour: Strata
Size: XS
X-LAB AD8 | 105 Di2 | Strata

X-LAB AD8 | 105 Di2 | Strata

AED 21,229.00
X-LAB AD8 | 105 Di2 | Strata
X-LAB AD8 | 105 Di2 | Strata
X-LAB AD8 | 105 Di2 | Strata
X-LAB AD8 | 105 Di2 | Strata
X-LAB AD8 | 105 Di2 | Strata
X-LAB AD8 | 105 Di2 | Strata
X-LAB AD8 | 105 Di2 | Strata

X-LAB AD8 | 105 Di2 | Strata

AED 21,229.00
Colour: Strata
Size: XS
GENERAL INFO
GENERAL INFO
x

The X-LAB AD8 105 Di2 is built for riders who want the performance of a race bike without compromising everyday rideability. Inspired by the WorldTour-proven AD9, it combines aerodynamic efficiency, responsive handling, and lightweight carbon construction into a bike that's ready for everything from fast training rides to race day.

Its aerodynamic frame is designed to help you carry speed with less effort, while the balanced geometry provides confidence through corners, descents, and long days in the saddle. Paired with Shimano 105 Di2 electronic shifting, every gear change is fast, accurate, and effortless, allowing you to stay focused on the ride ahead.

Finished in the striking Strata colourway, the AD8 blends modern performance with a distinctive look, making it just as impressive standing still as it is at full speed.

FEATURES
FEATURES
x

Branta carbon crankset with integrated power meter + Apple Find My anti-theft technology

Shimano 105 Di2 groupset

Branta C45 UL carbon wheelset with carbon spokes | 1,330 g

XDS carbon frameset with Toray T800 | Full bike 7.41kg

prev
TECHNICAL SPECS
TECHNICAL SPECS
x
Frame XDS Carbon Frame, Toray T-800, UDH Compatible
Fork XDS Carbon Fork, Toray T-800, 100x12mm Thru-axle
Handlebar / Stem Branta Carbon Integrated
Seatpost XDS Carbon Seatpost, Aero Profile
Rear Derailleur Shimano 105 RD-R7150 Di2
Front Derailleur Shimano 105 FD-R7150 Di2
Shifters Shimano 105 ST-R7170 Di2
Brakes Shimano 105 BR-R7170
Cassette Shimano 105 CS-R7101, 11-34T
Crankset Branta Carbon Power Meter Crankset, 52-36T,
29mm Alloy Spindle, Apple Find My Anti-Theft Technology
Bottom Bracket T47 29mm
Rotors Shimano SM-RT70, Front: 160mm / Rear: 140mm
Chain Shimano CN-M7100
Wheelset Branta C45 UL, Carbon Rims & Spokes
Tires Michelin Pro 5 700x28C
Max Tire Clearance: 32C
Saddle Selle Italia SLR Boost, Carbon Rails
Weight 7.41 kg / 16.3 lbs (Size L)
Size Options XS / S / M / L / XL
GEOMETRY
GEOMETRY
x
Basic geometry
title XS S M L XL
A — Seat Tube Length 470mm 495mm 515mm 540mm 565mm
B — Top Tube Length 504mm 523mm 540mm 559mm 579mm
C — Head Tube Length 105mm 118mm 130mm 148mm 171mm
D — Seat Tube Angle 75° 75° 74° 74° 73°
E — Head Tube Angle 71° 72° 73° 73° 73°
F — Chainstay 410mm 410mm 410mm 410mm 410mm
G — Wheelbase 970mm 978mm 982mm 992mm 1007mm
H — Bottom Bracket Drop 72mm 72mm 70mm 70mm 70mm
I — Stack 505mm 520mm 534mm 553mm 575mm
J — Reach 371mm 379mm 387mm 395mm 405mm
K — Front Center 575mm 582mm 583mm 592mm 607mm
O — Stand Over 753mm 774mm 792mm 811mm 834mm



Component geometry
title XS S M L XL
Fork Rate/Offset 48mm 48mm 43mm 43mm 43mm
Trail 67mm 63mm 64mm 61mm 59mm
Handlebar 360mm 360mm 380mm 380mm 400mm
Stem 90mm 90mm 100mm 100mm 120mm
Crankset 160mm 160mm 165mm 165mm 170mm
Seat Post 300mm 300mm 350mm 350mm 350mm
